Ball Race Butt Hinge 1580 CE

Suitable for medium to heavy flush doors Grade 11

Product features

• brass ball races running in hardened steel cups
• CE marked FD30 fire rated
• stainless steel pin
• brass Button Tip ends
• 10 year performance guarantee
• suitable for medium to heavy weight flush doors
• security bolt and radius corner options available
• handed left or right

Technical details

Load capacity: 80.0 kg
Knuckle diameter: 11.0 mm
Overall length: 152.4 mm
Overall width: 75.0 mm
Material thickness: 4.0 mm
Screws: 10.9 x 32.0 mm

Note

**Hinges are available with radius and security options and to contact the office for more information and pricing.

These products are made to order and generally take around 2 weeks - if you require urgently please contact the office.
