Delivery in 2-3 weeks
EV 835E10 N SOL
Price range: £152.23 through £193.47
for single-action (wall-glass) residential, heavy-duty and outer glass doors
Product features
- free swinging hinge
- for use with wall-glass combinations
- for single-action outer doors that are protected from severe weather conditions
- to be matched with EV 835E10 N – EV 835E11 N
- installed on doors with a profile on a stop
- rebate depth from 30 to 50 mm
Downloads
- Description
- Additional information
Description
Finishes
Technical details
Load capacity: 100,0 kg
Rebate depth: 30,0 – 50,0 mm
Opening angle: 180°
Glass thickness: 8 – 21,52 mm
Min. door width: 800,0 mm
Max. door width: 1000,0 mm
Suitable for
Type of door leaf: glass
Additional information
| Finish | Ev1 Satin Silver Natural, Satin Black, Similar Satin Stainless Steel, Polished Chromed, Matt Gray, Similar Polished Gold, Similar Matt Gold, Ral 9005 Jet Black Matt, Ral 9010 Pure White Matt, Ral 9016 Traffic White Matt |
|---|
