EV 835E50 SOL
Price range: £166.96 through £218.03
for single-action (glass-glass) heavy-duty and outer glass doors
Product features
- hydraulic hinge
- for use with glass-glass combinations
- for single-action outer doors that are protected from severe weather conditions
- with closing speed adjustment
- with constant braking control
- automatic closing from + 80°
- installed on doors with a profile on a stop
Downloads
- Description
- Additional information
Description
Finishes
Technical details
Load capacity: 120,0 kg
Opening angle: 180°
Automatic closing: + 80°
Glass thickness: 8 – 21,52 mm
Temperature range: – 15,0°C to + 40,0°C
Min. door width: 800,0 mm
Max. door width: 1000,0 mm
Suitable for
Type of door leaf: glass
Additional information
| Finish | Ev1 Satin Silver Natural, Satin Black, Similar Satin Stainless Steel, Polished Chromed, Matt Gray, Similar Polished Gold, Similar Matt Gold, Ral 9005 Jet Black Matt, Ral 9010 Pure White Matt, Ral 9016 Traffic White Matt |
|---|
