Simonswerk Tectus Concealed Hinge TE 540 3D A8 FR

with integrated intumescent kit for unrebated heavy-duty doors with claddings up to 8 mm on both sides

Product features

• with integrated intumescent kit
• cladding up to 8 mm
• completely concealed hinge system
• for timber, steel or aluminium frames
• for unrebated heavy-duty doors
• sideways closed hinge body for a homogeneous mortise appearance
• with comfortable 3D adjustment (side +/- 3,0 mm, height +/- 3,0 mm, compression +/- 1,0 mm)
• maintenance-free slide bearings

Technical details

LoaLoad capacity: 100.0 kg
Overall length: 200.0 mm
Width (door part): 32.0 mm
Width (frame part): 32.0 mm
Cutter diameter: 24.0 mm
Collar ring diameter: 30.0 mm
Opening angle: 180°

Suitable for

Type of door leaf: timber
Rebate: unrebated
Type of frame: aluminium frame, blind frame, block frame, casing frame, steel frame

Note

**These products are made to order and generally take around 2 weeks - if you require urgently please contact the office.
