VX 2505 3D N – Blue Galvanized

VX 7532 3D – Blue Galvanized
VX 7505 3D – Blue Galvanized

£33.71

for rebated and unrebated doors with blind frames

Product features

  • for rebated and unrebated doors
  • for blind frame
  • for heavy-duty hinges VARIANT VX and VARIANT VXG
  • comfortable 3D adjustment (side + 2.0/- 4.0 mm, height +/- 3.0 mm, compression +/- 3.0 mm)
  • adjustment with permanently fixed door
SKU: VX 2505 3D N Category:
Add product to your Wishlist

Description

Technical details

Load capacity: 200.0 kg
Cutter diameter: 24.0 mm
Collar ring diameter: 30.0 mm

Suitable for

Rebate: rebated, rebated flush, unrebated
Type of frame: blind frame

Note

The load capacity mentioned above refers to two hinges per door leaf (1 x 2 m). Also the load capacities of the respective combined receiver have to be taken into consideration.
