Delivery in 2-3 weeks
VX 7502 3D – Blue Galvanized
£26.14
for rebated and unrebated doors with casing frames
Product features
- for rebated and unrebated doors
- for casing frames
- for heavy-duty hinges VARIANT VX and VARIANT VXG
- continuous 3D adjustment (side +/- 3.0 mm, height +/- 3.0 mm, compression +/- 3.0 mm)
Downloads
- Description
Description
Technical details
Load capacity: 200.0 kg
Cutter diameter: 24.0 mm
Collar ring diameter: 30.0 mm
Suitable for
Rebate: rebated, rebated flush, unrebated
Type of frame: casing frame
Note
The load capacity mentioned above refers to two hinges per door leaf (1 x 2 m). Also the load capacities of the respective combined receiver have to be taken into consideration.
