VX 7511 3D
Price range: £22.95 through £45.75
for rebated and unrebated doors with steel frames
Product features
- for rebated and unrebated doors
- for steel frames
- for heavy-duty hinges VARIANT VX and VARIANT VXG
- continuous 3D adjustment (side +/- 3,0 mm, height +/- 3,0 mm, compression +/- 3,0 mm)
- with weld nuts
- Description
- Additional information
Description
Technical details
Load capacity: 200.0 kg
Suitable for
Rebate: rebated, rebated flush, unrebated
Type of frame: steel frame
Note
The load capacity mentioned above refers to two hinges per door leaf (1 x 2 m). Also the load capacities of the respective combined receiver have to be taken into consideration. For detailed information please look at the chapter technical information.
Als available as VX 7511 3D ER made of solid stainless steel.
Descriptive text
Finish
Additional information
| Finish | Blue galvanized, Stainless Steel untreated |
|---|
