Delivery in 2-3 weeks
VXG 7780/100 N – Satin Stainless Steel
£91.53
for glass doors with unrebated timber, steel or aluminium frames
Product features
- for unrebated timber, steel, aluminium frames
- for 3D adjustable VARIANT VX receivers
- intended for glass doors with vertical standard hole pattern
- for glass thicknesses of 8 and 10 mm
- internal torsion-proof pin
- concealed, maintenance-free axial-radial slide bearings
- Description
Description
Technical details
Load capacity: 60.0 kg
Knuckle length: 95.0 mm
Knuckle diameter: 20.0 mm
Pin diameter: 10.0 mm
Material thickness: 3.5 mm
Suitable for
Type of door leaf: glass
Rebate: unrebated
Type of frame: aluminium frame, blind frame, block frame, casing frame, steel frame
