Simonswerk Tectus Concealed Hinge TE 680 3D FD

SKU: TE 680 3D FD Categories: Simonswerk Collection, Simonswerk Hinges, TECTUS, Tectus Concealed Hinges

for rebated timber entrance doors

Finish: Satin Chrome Look

Product features

• concealed hinge system
• for rebated timber entrance doors
• sideways closed hinge body for a homogeneous mortise appearance
• comfortable 3D adjustment (side +/- 3,0 mm, height +/- 3,0 mm, compression +/- 1,5 mm)
• continuous sealing system
• 18 mm overlap width
• maintenance-free slide bearings

Technical details

Load capacity: 160.0 kg
Width (door part): 40.5 mm
Length (door part): 140.0 mm
Width (frame part): 30.0 mm
Length (frame part): 250.0 mm
Cutter diameter: 20.0 mm
Collar ring diameter: 30.0 mm
Opening angle: 180°

Suitable for

Type of door leaf: timber
Rebate: unrebated
Type of frame: aluminium frame, blind frame, block frame, casing frame, steel frame

Note

**These products are made to order and generally take around 2 weeks - if you require urgently please contact the office.
