VX 2501 3D N – Blue Galvanized

VX 7729/160-4 HA MSTS with VX 7531 3D and VX 7561 KR – Satin Stainless Steel
VX 2502 3D N – Blue Galvanized

£29.77

for rebated and unrebated doors with block frames

Product features

  • for rebated and unrebated doors
  • for block frames
  • for heavy-duty hinges VARIANT VX and VARIANT VXG
  • comfortable 3D adjustment (side + 2.0/- 4.0 mm, height +/- 3.0 mm, compression +/- 3.0 mm)
  • adjustment with permanently fixed door

Downloads

MA_VARIANT_VX_25_3D_Serie_de-en-fr-es

SKU: VX 2501 3D N Category:
Add product to your Wishlist

Description

Technical details

Load capacity: 200.0 kg
Cutter diameter: 24.0 mm
Collar ring diameter: 30.0 mm

Suitable for

Rebate: rebated, rebated flush, unrebated
Type of frame: block frame

Note

The load capacity mentioned above refers to two hinges per door leaf (1 x 2 m). Also the load capacities of the respective combined receiver have to be taken into consideration.
