VXG 7990/120
Price range: £77.02 through £80.20
for glass doors with rebated timber, steel or aluminium frames
Product features
- for rebated timber, steel, aluminium frames
- for 3D adjustable VARIANT VX receivers
- intended for glass doors with vertical standard hole pattern
- for glass thicknesses of 8 and 10 mm
- internal torsion-proof pin
- concealed, maintenance-free axial-radial slide bearings
- Description
- Additional information
Description
Technical details
Load capacity: 80.0 kg
Knuckle length: 120.0 mm
Knuckle diameter: 20.0 mm
Pin diameter: 10.0 mm
Material thickness: 3.5 mm
Suitable for
Type of door leaf: glass
Rebate: rebated
Type of frame: aluminium frame, blind frame, block frame, casing frame, steel frame
Note
The load capacity mentioned above refers to the use of 2 hinges per door leaf (1 x 2 m), for detailed information please look at the chapter technical information.
Finish
Additional information
| Finish | Satin Stainless Steel, RAL 9005 Matte Black |
|---|
