Delivery in 2-3 weeks
VT 101E10
£298.56
for double-action residential, heavy-duty and outer glass doors up to 100 kg
Product features
- hydraulic hinge
- for double-action outer doors that are protected from severe weather conditions
- integrated brake (function to prevent self-opening)
- with closing speed adjustment
- with final latch adjustment
- designed for pivoting applications
- hold open function at + 90° and – 90°
- automatic closing from + 80° and – 80°
- version without cover caps
Downloads
- Description
- Additional information
Description
Finishes
Technical details
Load capacity: 100,0 kg
Opening angle: +/- 90°
Hold open: + 90°, – 90°
Automatic closing: + 80°, – 80°
Glass thickness: 8 – 13,52 mm
Temperature range: – 10,0°C to + 50,0°C
Max. door width: 1000,0 mm
Suitable for
Type of door leaf: glass
Additional information
| Finish | Raw (CO 000) |
|---|
